PLANET Mesh Network Manager Guide
PLANET Mesh Network Manager Guide
Page
126 of 126
6 Technical Support
For Technical Support and other related feedback and information request, kindly please send
your request to the following email:
Email: support_wireless@planet.com.tw
In your email, please provide the following detail information:
Device Model No
:
Distributor
:
Date of Purchase
:
Device MAC Address
:
Brief Description of your
Problem or Request
:
Capture of Sys Log Info
:
Contact Info
Name
:
Company
:
Email
:
