PLANET Mesh Network Manager Guide
PLANET Mesh Network Manager Guide
Page
103 of 126
3) Client IP Start
• The start of IP Address range assigned for the client
• Data type: IP Address
4) Client IP Stop
• The end of IP Address range assigned for the client
• Data type: IP Address
Parameters (PPTP Server Table)
1) Username
• The user name for the VPN client
• Data type: Display String
2) Password
• The password corresponds to the username
• Must re-enter the same password at the Confirm field.
• Data type: Display String
3) IP Address
• The IP Address assigned to the client
• The IP MUST be in the range of the Client IPs pre-defined
• Data type: IP Address
4) Comment
• An optional comment regarding the PPTP client.
• Data type: Display String
5) Active
• Define the status of the PPTP Server table entry, either active or inactive
