PLANET Mesh Network Manager Guide
PLANET Mesh Network Manager Guide
Page
116 of 126
5) Certificate Password
• The password for the HTTP certificate
• Data type: Display String, default value is “httpconf”
6) Enable Access Control
• A checkbox to enable or disable the access control of the HTTP daemon.
Parameters (HTTPD Access Table)
1) Device
• The name of the device allowed for access control
• Data type: Octet String
2) Subnet
• The subnet allowed for access control
• Data type: IP Address
3) Netmask
• The netmask for the Subnet IP above
• Data type: IP Address
4) Using
• Define the type of access control to use through, either Device or Subnet
5) Comment
• An optional comment regarding the table entry
• Data type: Display String
6) Active
• Define the status of the table entry, either active or inactive
