PLANET Mesh Network Manager Guide
PLANET Mesh Network Manager Guide
Page
92 of 126
Parameters
1) Enable NTP Service
• A checkbox to enable the NTP service of the system
2) Time Zone
• A list of time zones is available in the drop down list. Select the appropriate
one to synchronize.
Parameters (NTP Table columns)
1) Server
• The NTP server host name
• Data type: DNS String
2) Min Pool
• The minimum pool time of the server, in seconds
• Data type: Integer, default value is 4
3) Max Pool
• The maximum pool time of the server, in seconds
• Data type: Integer, default value is 10
4) Comment
• An optional comment regarding the NTP Table entry
• Data type: Display String
5) Active
• The status of the NTP Table entry, either active or inactive
