Troubleshooting by Indication on the Remote Controller Si30-813
210 Troubleshooting
2.27
“
J5
”
Outside Unit: Malfunction of Thermistor (R2T) for
Suction Pipe
Remote
Controller
Display
J5
Applicable
Models
Outside unit
RWEYQ8P, 10P
Method of
Malfunction
Detection
Malfunction is detected from the temperature detected by the suction pipe temperature
thermistor.
Malfunction
Decision
Conditions
When a short circuit or an open circuit in the suction pipe temperature thermistor is detected.
Supposed
Causes
Defect of thermistor (R2T) for outside unit suction pipe
Defect of outside unit PC board (A1P)
Troubleshooting
∗
1: Refer to thermistor resistance / temperature characteristics table on P.309.
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Resistance
is normal when
measured after
disconnecting the thermistor
(R2T) from the outside
unit PC board.
(3.5kΩ ~
360kΩ)
∗1
Replace outside unit PC board
(A1P).
Connect the connector and turn on
again.
NO
NO
Replace the thermistor R2T.
YES
YES
Connector
is connected to
X37A, of outside unit
PC board.
(A1P)
