List of Electrical and Functional Parts Si30-813
300 Appendix
3. List of Electrical and Functional Parts
3.1 Outside Unit
3.1.1 RWEYQ8PY1, 10PY1, 10PYL
3.1.2 RWEYQ10PTL
Item Name Symbol
Model
RWEYQ8PY1, 10PY1, 10PYL
Compressor Inverter
Type
M1C
JT1G-VDKYR@T
OC protection
device
13.5A
Electronic expansion valve (Main) Y1E Fully closed: 0pls Fully open: 2000pls
Electronic expansion valve (Subcool) Y2E Fully closed: 0pls Fully open: 2000pls
Pressure
protection
High pressure
switch
For M1C HPS OFF: 4.0 MPa ON: 3.0±0.15MPa
Low pressure sensor S1NPL OFF: 0.07MPa
Fusible plug — Open: 70~75°C
Temperature
protection
Discharge gas temperature
protection
(Discharge pipe thermistor)
R3T OFF: 135°C
Inverter fin temperature
protection
(Radiator fin thermistor)
R1T OFF: 98°C
Others Fuse
For main PC
board
F1U 250V AC 10A Class B
F2U 250V AC 10A Class B
For Noise filter
PC board
F1U 250V AC 5A Class B
+
0
−
0.12
Item Name Symbol
Model
RWEYQ10PTL
Compressor Inverter
Type
M1C
JT100G-VDK@SB
OC protection
device
24.0A
Electronic expansion valve (Main) Y1E Fully closed: 0pls Fully open: 2000pls
Electronic expansion valve (Subcool) Y2E Fully closed: 0pls Fully open: 2000pls
Pressure
protection
High pressure
switch
For M1C HPS OFF: 4.0 MPa ON: 3.0±0.15MPa
Low pressure sensor S1NPL OFF: 0.07MPa
Fusible plug — Open: 70~75°C
Temperature
protection
Discharge gas temperature
protection
(Discharge pipe thermistor)
R3T OFF: 135°C
Inverter fin temperature
protection
(Radiator fin thermistor)
R1T OFF: 98°C
Others Fuse
For main PC
board
F1U 250V AC 10A Class B
F2U 250V AC 10A Class B
For Noise filter
PC board
F1U 250V AC 5A Class B
+
0
−
0.12
