Troubleshooting (OP: Unified ON/OFF Controller) Si30-813
262 Troubleshooting
Check for causes of drop in low pressure
CHECK 2
Abnormal piping length
Degradation in
evaporating
capacity
[In cooling]
Short circuit
Low ambient temperature
← Are the coil resistance and insulation normal?
← Can the fan motor be rotated with hands?
Are the motor coil resistance and
insulation normal?
← If a spare PC board is mounted, is the
capacity setting properly made?
← Is the air filter clogged?
← Is there any obstacle in the air passage?
← Is the water temperature at the water heat
exchanger inlet not less than 10°C?
← Is the water heat exchanger clogged?
← Is the piping length in the permissible range?
← Conduct visual checks for pipe conditions.
← Is there any temperature difference around
the filter or the branch pipe?
← Check to be sure the stop valve is open.
[In heating]
Moisture choke
← Eliminate moisture by vacuum break.
∗1 : For details of the compressor capacity control while in cooling, refer to “Compressor Control” on page 71.
∗2 : The “low pressure protection control” includes low pressure drop control and hot gas bypass control. For
details, refer to page 77.
∗3 : In cooling, the indoor unit electronic expansion valve is used for “superheated degree control”. (For details,
refer to page 95.)
∗4 : In heating, the outdoor unit electronic expansion valve (Y1E) is used for “superheated degree control of
outside unit heat exchan
g
er”. (For details, refer to pa
g
e 73.)
Referring to the Fault Tree Analysis (FTA) shown below, identify the faulty points.
Abnormally low
low-pressure (Low
evaporating
temperature)
←
Does the pressure value of the Service
Checker match the reading of the pressure sensor?
← Are the voltage characteristics normal?
← Are the coil resistance and insulation normal?
← Are the voltage characteristics normal?
←
Does the pressure value of the Service
Checker match the reading of the pressure sensor?
← Check for the thermistor resistance and connection.
← Check for the thermistor resistance and connection.
← Does the pressure value of the Service Checker
match the reading of the pressure sensor?
← Are the coil resistance and insulation normal?
← Are the voltage characteristics normal?
← Check for the thermistor resistance and connection.
← Is the suction air temperature not less than 14°C?
← Is the indoor temperature not more than 14°C?
← Is the connector properly connected?
Are the thermistor resistance characteristics normal?
Less circulation
quantity of
refrigerant
High pipe
resistance
Inadequate refrigerant quantity
Bent or Crush of pipe
Clogging of foreign particles
Stop valve closed
Low water temperature at the water heat exchanger inlet
Dirty water heat exchanger
Faulty low
pressure
control
[In cooling]
(∗1)
[In both cooling
and heating]
(∗2)
[In cooling]
If the indoor unit
electronic
expansion valve
is excessively
throttled
(∗3)
Faulty electronic
expansion valve
control
[In heating]
If the outside unit
electronic
expansion valve
is excessively
throttled
(∗4)
Faulty
compressor
capacity
control
Faulty low
pressure
protection control
Faulty indoor unit
electronic
expansion valve
Faulty
control
Faulty outside
unit electronic
expansion valve
Faulty
control
Faulty low pressure sensor
Faulty control PC board
Faulty low pressure sensor
Faulty hot gas solenoid valve
Faulty control PC board
Faulty valve coil
Faulty valve body
Faulty gas pipe thermistor
of indoor unit
Faulty liquid pipe thermistor
of indoor unit
Faulty control PC board
Faulty valve coil
Faulty valve body
Faulty low pressure sensor
Faulty suction pipe thermistor
Faulty control PC board
Low suction air
temperature of
indoor unit
Faulty suction air thermistor of indoor unit
Decreased
fan airflow
rate
Decreased
fan output
High air
passage
resistance
Faulty fan motor
Faulty control PC
board (including
capacity setting)
Dirty filter
Obstacle
← Refer to CHECK 6
