Si30-813 Specifications
Specifications 19
1.2 60Hz
Notes:
1.
★
1 Indoor temp. : 27°CDB, 19.5°CWB / inlet water temp.: 30°C / Equivalent piping length: 7.5m, level
difference: 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / inlet water temp.: 30°C / Equivalent piping length: 7.5m, level
difference: 0m.
★
3 Indoor temp. : 20°CDB / inlet water temp.: 20°C / Equivalent piping length: 7.5m, level difference: 0m.
★
4 In the case of heat pump system, suction gas pipe is not used.
★
5 In the case of heat recovery system.
★
6 In the case of heat pump system.
★
7 Basically
φ
31.8, but use
φ
34.9 for availability of oversea market.
2. This unit cannot be installed in the outdoors.
Install indoors (Machine room, etc).
3. Hold ambient temperature at 0~40°C and humidity at 80%RH or less
Heat rejection from the casing
: RWEYQ10PTL, PYL / 0.71kW
Model Name (Combination Unit)
YL
RWEYQ10PYL RWEYQ20PYL RWEYQ30PYL
Model Name (Independent Unit) — RWEYQ10PYL+RWEYQ10PYL
RWEYQ10PYL+RWEYQ10PYL+RWEYQ10PYL
Model Name (Combination Unit)
TL
RWEYQ10PTL RWEYQ20PTL RWEYQ30PTL
Model Name (Independent Unit) — RWEYQ10PTL+RWEYQ10PTL
RWEYQ10PTL+RWEYQ10PTL+RWEYQ10PTL
★
1 Cooling Capacity (19.5°CWB)
kcal / h 23,200 46,400 69,700
Btu / h 92,100 184,000 276,000
kW 27.0 54.0 81.0
★
2 Cooling Capacity (19.0°CWB) kW 26.7 53.4 80.1
★
3 Heating Capacity
kcal / h 27,100 54,200 81,300
Btu / h 107,000 215,000 322,000
kW 31.5 63.0 94.5
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm 1,000×780×550 (1,000×780×550)×2 (1,000×780×550)×3
Heat
Exchanger
Type Stainless Steel Plate Type Stainless Steel Plate Type Stainless Steel Plate Type
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 14.61 (14.61)×2 (14.61)×3
Number of Revolutions r.p.m 6,900 (6,900)×2 (6,900)×3
Motor Output×Number
of Units
kW 4.2 (4.2)×2 (4.2)×3
Starting Method Soft start Soft start Soft start
Refrigerant
Connecting
Pipes
Liquid Pipe mm
φ
9.5 (Flare)
φ
15.9 (Flare)
φ
19.1 (Flare)
★
4 Suction Gas Pipe mm
φ
22.2 (Brazing)
φ
28.6 (Brazing)
φ
34.9 (Brazing)
★
7
HP/LP gas pipe mm
★
5
φ
19.1,
★
6
φ
22.2 (Brazing)
★
5
φ
22.2,
★
6
φ
28.6 (Brazing)
★
5
φ
28.6,
★
6
φ
34.9 (Brazing)
Water
Connecting
Pipes
Water inlet PT1 1/4B internal thread
Water outlet PT1 1/4B internal thread
Drain outlet PS 1/2B internal thread
Machine Weight kg 150 150+150 150+150+150
Safety Devices
High Pressure Switch, Inverter
Overload Protector, Fusible Plugs
High Pressure Switch, Inverter
Overload Protector, Fusible Plugs
High Pressure Switch, Inverter
Overload Protector, Fusible Plugs
Capacity Control % 23~100 11~100 8~100
Refrigerant
Refrigerant Name R-410A R-410A R-410A
Charge kg 4.2 4.2+4.2 4.2+4.2+4.2
Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Connection Pipes, Clamps, Installation
Manual, Operation Manual, Strainer
Connection Pipes, Clamps, Installation
Manual, Operation Manual, Strainer
Connection Pipes, Clamps, Installation
Manual, Operation Manual, Strainer
Drawing No. C : 4D062118, 4D062121 C : 4D062119, 4D062122 C : 4D062120, 4D062123
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
