CALL PROCEDURE
7
!1 When receiving an acknowledgement, the display
shows the received ID code, or the called station
name.
• Push [FREQ/CH];
-to select the traffic frequency if the called station is
able to comply to the call.
- to return to DSC watch mode when unable.
!2 Announce the following message to the connected
station.
•“PAN PAN”
•Desired station name (repeated 3
times).
•“This is ..... (your ship name).”
•The 9-digit identity AND the call sign (or
other identification of the ship)
• The text of the urgency message.
************************
*
Individual
ACK
*
*
IC-M802
*
*
Able
to
comply
*
************************
Exit
************************
*
Individual
ACK
*
*
IC-M802
*
*
Unable
to
comply
*
*
Operator
unavailable
*
************************
Exit
When the called station is unable to comply
to the call, the reason may be displayed.
IC-M802_USA.qxd 02.5.30 11:40 Page 27
