Icom IC-M802 [8/78] D regular distress call
![Icom IC-M802 [8/78] D regular distress call](/views2/1074299/page8/bg8.png)
V
QUICK REFERENCE
2001 NEW
DD
Regular distress call
q Push [DSC] to enter DSC watch mode.
w Push [MODE
SET
] to enter DSC menu.
e Rotate [CH] to select “Distress” then push
[ENT]
r Rotate [CH] to select the desired nature then push
[ENT].
t Verify your position and the UTC time, then push
[ENT].
•When no NMEA0183 ver. 3.01 data is applied to [GPS],
your position and UTC time should be input in this step.
-Use the keypad and [CH] when changing your posi-
tion or the time.
- Move the cursor with [CH] rotation.
-[3
SCAN
], [6
RF
-
G
], [7 Lo] and [9 Hi] is used for the
‘East,’‘North,’‘South’ and ‘West’ selection.
y Rotate [CH] to select the DSC calling frequencies,
then push [ENT].
•After pushing [ENT], return to DSC menu as shown in
step e.
u Lift up the distress switch cover, then push and
hold [DISTRESS] for 5 sec.
[DISTRESS]
*******
Distress
*******
--------
Attempt
-------
Single;six
frequency
Single;
2187.5kHz
Single;
4207.5kHz
Single;
6312.0kHz
Single;
8414.5kHz
Single;12577.0kHz
Single;16804.5kHz
OKSEL
Ç
*******
Distress
*******
---
Position
&
time
----
Latitude
Longitude
UTC
34
34'N
135
34'E
12:34
OKNull
*******
Distress
*******
--------
Nature
--------
Undesignated
Fire,Explosion
Flooding
Collision
Grounding
Capsizing
Sinking
Disable
adrift
Abandoning
ship
Piracy
attack
Man
overboard
EPIRB
emission
Ç
OKSEL
*******
DSC
MENU
*******
--------
Select
--------
Position
Individual
Group
All
ships
Position
REQ
Distress
Test
RX
memory
TX
memory
Set
up
Exit
Ç
OKSEL
[MODE SET]
[ENT][CH]
[DSC]
IC-M802_USA.qxd 02.5.30 11:39 Page V
