9
43
MEMORY OPERATION
2001 NEW
9
8
■ Memory description
The IC-M802 has several kinds of memories as fol-
lows:
• Address and group ID code memories (p. 44)
• Call, traffic and scan frequency memories. (p. 45)
•DSC transmission memory (described in this section)
• Received message memory (p. 38)
■ Memory writing
10 DSC transmission memory channels allow you to
set often used format specifiers and contents such as
for routine calls, group calls, etc.
q During DSC watch mode, select the desired format
category (except distress and test), and set the
message, traffic and call frequencies until the call
stand-by screen is displayed as described in the
CALL PROCEDURE section (pgs. 23–35).
w Push and hold [ENT] for 1 sec. to select the TX
memory write condition.
e Rotate [CH] to select the desired memory channel.
r Push and hold [ENT] for 1 sec. again to store the
condition into the selected memory channel.
•The set DSC format and calling station ID/name ap-
pear.
t Push [ENT] to return to the calling stand-by condi-
tion, or push [MODE
SET
] to return to DSC watch
mode.
---
TX
memory
write
----
0:Individual
987654321
1:
2:
3:
4:
5:
Ç
OKSEL
---
TX
memory
write
----
0:
1:
2:
3:
4:
5:
Ç
WriteSEL
■ Memory reading/transmitting/deleting
q Push [DSC] to select DSC watch mode, if neces-
sary.
w Push [TX
TXF
] to enter the DSC transmit memory
screen.
•Or, push [MODE
SET
], rotate [CH] to select “TX
memory” then push [ENT], also selects the transmit
memory screen.
e Rotate [CH] to select the selected memory chan-
nel to be read.
r Push [ENT] to display the memory contents.
t Operate as follows:
➥ When reading the memory contents only;
•Push [MODE
SET
] to return to DSC watch
mode.
➥ When transmitting the memory contents;
• Push and hold [CANCEL/CALL] for 1 sec.
➥ When clearing the memory contents;
• Push and hold [CE] for 1 sec.
******
TX
memory
*******
------
Individual
------
Category:Distress
To:987654321
Traffic:J3E
TX
2134.0kHz
RX
2134.0kHz
Call
Freq:TX
2187.5kHz
RX
2187.5kHz
DEL
Call
******
TX
memory
*******
--------
Select
--------
0:Individual
987654321
1:
2:
3:
4:
5:
Ç
OKSEL
IC-M802_USA.qxd 02.5.30 11:40 Page 43
