DSC MENU OPERATION
2001 NEW
■ Verifying self-ID
➥ During setup select menu indication, rotate [CH] to
select “MMSI check” then push [ENT] to dis-
play the programmed MMSI ID (self-ID).
➥ Push [DSC] to select DSC watch mode.
➥ Push [MODE
SET
] to select DSC menu.
➥ Rotate [CH] to select “Set up” then push [ENT].
•Push [MODE
SET
] to return to DSC watch mode, or
push [FREQ/CH] to return to the select screen.
********
Set
up
********
------
MMSI
check
------
ID:123456789
OK
Cancel
■ Memory reading/deleting
q During setup select menu indication, rotate [CH] to
select the desired memory item then push [ENT].
• Push [DSC] to select DSC watch mode.
• Push [MODE
SET
] to select DSC menu.
• Rotate [CH] to select “Set up” then push [ENT].
w Rotate [CH] to select the desired memory, then
push [ENT].
e Operate as follows:
➥ When reading the memory contents only;
•Push [ENT] to return to the appropriate mem-
ory list screen.
➥ When deleting the memory contents;
• Push and hold [CE] for 1 sec.
-After deleting, the appropriate memory list screen
is displayed automatically.
********
Set
up
********
********
Set
up
********
--
Traffic
frequency
---
----
Call
frequency
----
********
Set
up
********
----
Scan
frequency
----
DEL OK
Comment:ICOM
Group
TX:
4567.0kHz
RX:
4567.0kHz
********
Set
up
********
------
Address
ID
------
********
Set
up
********
-------
Group
ID
-------
DEL OK
Name:ICOM
M802
ID:012345678
TX:
2345.0kHz
RX:
2345.0kHz
IC-M802_USA.qxd 02.5.30 11:40 Page 46
