Skil 5255 LA [11/164] Application advice

! the wide part of the foot should rest on the

supported part of the workpiece

- can be adjusted to allow you to choose whether waste

material is on inner or outer side of blade 6b

! cutting width is determined by width of blade

teeth and not by width of blade body

! always make trial cuts first to verify actual line of

cut

• Dust suction

- connect vacuum cleaner to extension R 7

! never let the vacuum cleaner hose interfere with

the lower guard or the cutting operation

- one may also use a dust bag (SKIL accessory

2610387402)

• Operating the tool 7

- connect plug to power source

- always hold handle S rmly with one hand and handle

T rmly with the other hand

- place tool with front end of foot at on workpiece

! ensure that the saw teeth are not engaged into

the workpiece

- switch on tool by rst pressing knob V (= safety switch

which cannot be locked) and then pulling trigger W

! the tool should run at full speed before the blade

enters into the workpiece

- lower guard F opens automatically when saw blade

enters the workpiece (open lower guard manually by

using lever G only for special cuts such as plunge

cuts)

! do not force the tool (apply light and continuous

pressure in order to avoid overheating the blade tips

and, in case of cutting plastics, melting the plastic

material)

! while working, always hold the tool at the

grey-coloured grip area(s)

- after completing the cut switch o tool by releasing

trigger W

! ensure that the blade has come to a complete

standstill, before you lift the tool from the

workpiece

APPLICATION ADVICE

• When using guide-rail (SKIL accessory 2610Z04064) in

combination with adapter, the depth of cut will be

reduced with 14 mm for 90° as well as 45° cuts

• Always face the good side of the workpiece down to

ensure minimum splintering

• Only use sharp saw blades of the correct type 8

- quality of cut improves by the number of teeth

- carbide tipped blades stay sharp up to 30 times longer

than ordinary blades

• Parallel guide Y 9

- for making exact cuts along a workpiece edge

- can be inserted in either side of foot

Adjusting parallel guide

- loosen knob Z

- adjust to desired cutting width by using parallel guide

scale (use saw line visor Q as 0-reference)

- tighten knob Z

• Plunge cutting 0

- set desired cutting depth

- tilt tool forward with saw line visor Q lined up with

desired line of cut marked on the workpiece

- open lower guard F with lever G

- just before blade enters workpiece, switch on tool and

gradually lower back end of tool using front end of foot

as hinge-point

- gradually move tool downward as well as forward

- as soon as blade enters the material, release lever G

! never pull tool backwards

• Cutting large panels !

- support panel close to the cut either on oor, table or

workbench

! set cutting depth so that you cut through panel

and not through support

- in case parallel guide does not allow desired width of

cut, clamp or nail straight piece of wood to workpiece

as a guide, and use the right side of the foot against

this guide

MAINTENANCE / SERVICE

• This tool is not intended for professional use

• Always keep tool and cord clean (especially the

ventilation slots)

! disconnect the plug before cleaning

• Always keep the area around lower guard F 3 clean

(remove dust and chips by blowing out with compressed

air or with a brush)

• Clean saw blade immediately after use (especially from

resin and glue)

• If the tool should fail despite the care taken in

manufacturing and testing procedures, repair should be

carried out by an after-sales service centre for SKIL

power tools

- send the tool undismantled together with proof of

purchase to your dealer or the nearest SKIL service

station (addresses as well as the service diagram of

the tool are listed on www.skil.com)

ENVIRONMENT

• Do not dispose of electric tools, accessories and

packaging together with household waste material

(only for EU countries)

- in observance of European Directive 2012/19/EC on

waste of electric and electronic equipment and its

implementation in accordance with national law,

electric tools that have reached the end of their life

must be collected separately and returned to an

environmentally compatible recycling facility

- symbol @ will remind you of this when the need for

disposing occurs

DECLARATION OF CONFORMITY

• We declare under our sole responsibility that the product

described under “Technical data” is in conformity with the

following standards or standardization documents: EN

60745, EN 61000, EN 55014, in accordance with the

provisions of the directives 2004/108/EC, 2006/42/EC,

2011/65/EU
