Chapter 8. Device Management
129
New System Time
Use these fields to change the switch’s time and date settings, as follows:
To set the switch’s time and date to match the time and date of the
computer you are logged in to, select the Synchronize with computer time
radio button.
Note: Your computer’s time and date are displayed in the fields just below the
heading. These fields are for information purposes only.
To set the time and date to values of your choosing, select the Set
manually radio button and key the settings into their appropriate fields
using the YYYY-MM-DD and HH:MM:SS formats.
Note: Date/time formats may differ depending on the selected interface
language.
To have the time automatically synchronized to a network time server,
select the Synchronize with NTP server radio button:
If you want to use your network’s default time server, put a check in
the Using default NTP server checkbox.
If you want to specify a time server, make sure that the Using default
NTP server checkbox is unchecked, then key in the IP address of the
time server of your choice in the Primary NTP Server field. If you
want to configure an alternate time server, key in the IP address of the
time server in the Alternate NTP Server field.
Click Save to apply the changes.
Time Zone
To establish the time zone that the Serial Console Server is located in, drop
down the Time Zone list and choose the city that most closely corresponds
to where it is located.
Click Save to apply the changes.
