Serial Console Server User Manual
150
SN0132CO / SN0148CO (AXA Platform)
Function SN0132CO SN0148CO
Serial Connections 32 48
Connectors Serial 32 x RJ45 Female 48 x RJ45 Female
LAN 2 x RJ45
Power 2 x IEC 60320/C14
PON 1 x RJ45 Female (Reserved)
Modem 1 x RJ45 Female
USB 3 x USB Type A Female
USB Console (LUC) 1 x Mini USB
Local Console 1 x RJ45 Female
Switches Reset 1 x Recessed Pushbutton
Power 2 x Rocker Switch
LEDs Serial Port Status 32 (Green) 48 (Green)
10 / 100 / 1000 Mbps 2 (Red / Orange / Green)
Power 2 (Blue)
I/P Rating AC 100-240V~; 50/60Hz; 1.8A
Power Consumption
AC 110 V:9.8 W
AC 220 V:9.7 W
AC 110 V:10.3 W
AC 220 V:10.2 W
Mode of Operation Console Management, Console Management
Direct, Real Com Port, TCP Server/Client, UDP
Server/Client, Virtual Modem
Environment Operating Temp. 0–40° C
Storage Temp. -20–60° C
Humidity 0–80% RH Noncondensing
Physical Properties Housing Metal
Weight 4.55 kg 4.61 kg
Dimensions L x W x H 43.84 x 32.77 x 4.40 cm
