Serial Console Server User Manual
154
SN9108CO / SN9116CO (AXA Platform)
Function SN9108CO SN9116CO
Serial Connections 8 16
Connectors Serial 8 x RJ45 Female 16 x RJ45 Female
LAN 1 x RJ45
Power 1 x IEC60320/C14
Switches Reset 1 x Recessed Pushbutton
Power 1 x Rocker Switch
LEDs Serial Port Status 8 (Green) 16 (Green)
10 / 100 / 1000 Mbps 1 (Red / Orange / Green)
Power 1 (Blue)
I/P Rating AC 100-240V~, 50/60 Hz, 1A
Power Consumption
AC 110V:9.7W
AC 220V:9.6W
AC 110V:10.9W
AC 220V:11.6W
Mode of Operation Console Management, Console Management
Direct, Real Com Port, TCP Server/Client, UDP
Server/Client, Virtual Modem
Environment Operating Temp. 0–40° C
Storage Temp. -20–60° C
Humidity 0–80% RH Noncondensing
Physical Properties Housing Metal
Weight 3.12 kg 3.16 kg
Dimensions L x W x H 43.72 x 21.76 x 4.40 cm
(19”1U)
43.72 x 21.76 x 4.40 cm
(19”1U)
