Appendix
179
Backup/Restore Config Commands
backup pwd <password> path <usb1/usb2/usb3>
Example:
backup pwd pppWWW path usb1
Description:
Backup the system configuration and save it to the external USB drive
“USB1”. Also encrypt this backup file with the password “pppWWW”.
Note: This feature is for SN01xxCO / SN01xxCOD only.
restore pwd <password> path <usb1/usb2/usb3> filename
<file_name>
Example:
restore pwd pppWWW path usb1 filename sysconf.dat
Description:
Restore the encrypted system configuration file “sysconf.dat” from the root
directory of the external drive “USB1”, and decrypt it with the password
“pppWWW”.
Note: This feature is for SN01xxCO / SN01xxCOD only.
backup pwd <password> path <tftp://host_address/folder>
Example:
backup pwd pppWWW path tftp://192.168.0.100/ATEN
Description:
Backup the system configuration to the TFTP site whose IP is “192.168.0.100”
and the path is “/ATEN”. Also encrypt this backup file with the password
“pppWWW”.
