Chapter 2. Hardware Setup
27
Serial Console Server Installation
SN0108CO / SN0116CO / SN0132CO / SN0148CO Installation
To set up your SN0108CO / SN0116CO / SN0132CO / SN0148CO
installation, refer to the Installation Diagram on page 29. The numbers in the
diagram correspond to the numbers of the instruction steps, below:
1. Use a grounding wire to ground the unit by connecting one end of the wire
to the Serial Console Server’s grounding terminal (located on the back
panel), and the other end of the wire to a suitable grounded object.
Note: Do not omit this step. Proper grounding helps to prevent damage to
the unit from surges or static electricity.
2. For each server or serial device with a DB-9 connector, connect a Cisco
Console Cable or a Cat 5e cable with RJ-45-to-DB-9(F) adapter between
its serial port and any available RJ-45 port on the Serial Console Server’s
rear panel.
Note: Refer to DB-9/DB-25 Interface on page 165 for pin assignments.
3. Connect a Cat 5e cable between a Cisco Network Switch (or any
compatible network switch) and any available RJ-45 port on the Serial
Console Server’s rear panel.
Note: For a compatible network switch, please make sure the RJ-45 port
pin definition of the target device matches the Serial Console Server.
Examples of compatible network switches: Juniper, HPE, Dell,
Huawei, H3C, EdgeCore, TRENDnet, Fortinet and ATEN ES0152.
4. Connect the Serial Console Server to the network by connecting both the
primary and backup LAN ports, located on the unit’s rear panel, to the
network with Cat 5e cables.
5. (Optional) If you choose to install a serial modem for OOB operation,
connect a Cisco Console Cable to a null modem adapter. Plug the DB-9
connector into the Modem and the RJ-45 connector into the Modem Port
on the Serial Console Server’s front panel.
6. (Optional) Connect a Cat 5e cable between an ATEN PDU and the PON
Port on the Serial Console Server’s front panel for power management.
