Aten SN0116CO [54/203] Network setup

Serial Console Server User Manual

Setup

Network Setup

To set up the network, do the following:

1. Click the Device Management tab.

2. Select the Network tab.

3. Fill in the fields according to the information provided under Network,

page 103.
