Aten SN0116CO [182/203] Self signing ssl tls certificate

Serial Console Server User Manual

166

Self-signing SSL/TLS Certificate

Privately-trusted SSL/TLS certificates should only be used to authenticate

users and devices within an internal network.

1. On the SN device’s web browser, go to Maintenance > Private

Certificate.

2. Click Get CSR from the bottom of the Private Certificate page, as shown

here. A custom.csr file is obtained.

3. Utilizing openssl.exe, use the following commands to generate a new.cer

file:

 openssl req -new -newkey rsa:2048 -days 3653 -nodes -x509 -

keyout ca.key -out ca.cer

 openssl ca -policy policy_anything -config openssl.cnf -cert ca.cer -in

custom.csr -keyfile ca.key -days 360 -out new.cer

4. Click Import to import the new.cer file into your SN device.
