Aten SN0116CO [199/203] Ip filter commands

Appendix

183

IP Filter Commands

ipfilter <include/exclude>

Example:

ipfilter include

Description:

Enable IP filter function on include mode.

ipfilter off

Example:

ipfilter off

Description:

Disable IP filter function.

ipfilter

Example:

ipfilter

Description:

Show a list of all the filter conditions.

ipfilter cond <filter_condition> add

Example:

ipfilter cond 192.168.0.10 add

Description:

Add “192.168.0.10” to be one of the filter conditions to include/exclude this IP

address.

Note:

 Use a comma to separate multiple addresses. (e.g. 192.168.1.10,

192.168.1.99)
