Serial Console Server User Manual
180
restore pwd <password> path <tftp://host_address/
folder> filename <file_name>
Example:
restore pwd pppWWW path tftp://192.168.0.100/ATEN
filename sysconf.dat
Description:
Restore the encrypted system configuration file “sysconf.dat” from the TFTP
site whose IP is “192.168.0.100” and the path is “/ATEN”, and decrypt it with
the password “pppWWW”.
backup pwd <password> path <ftp://host_address/folder>
ftpuser <username> ftppwd <password>
Example:
backup pwd pppWWW path ftp://192.168.0.100/ATEN ftpuser
willy ftppwd pppWWW
Description:
Backup the system configuration and save it to the FTP site whose IP is
“192.168.0.100” and the path is “/ATEN”, and encrypt this backup file with the
password “pppWWW”. The user name for logging in to the FTP site is “willy”
and the login password is “pppWWW”.
restore pwd <password> path <ftp://host_address/folder>
filename <file_name> ftpuser <username> ftppwd
<password>
Example:
restore pwd pppWWW path ftp://192.168.0.100/ATEN
filename sysconf.dat ftpuser willy ftppwd pppWWW
Description:
Restore the system configuration file “sysconf.dat” from the FTP site whose IP
is “192.168.0.100” and the path is “/ATEN”, and decrypt it with the password
“pppWWW”. The user name for logging in to the FTP site is “willy” and the
login password is “pppWWW”.
