Appendix
173
session
Example:
session
Description:
List the currently logged-in users.
session name <username> delete
Example:
session name willy delete
Description:
Kill the specific session “willy”.
session index <index_number> delete
Example:
session index 1 delete
Description:
Kill the specific session with index 1.
user name <username> pwd <password> group <group name>
role <1/2/3> add
Example:
user name gene pwd pppWWW group SD1 role 1 add
Description:
Create a user account whose user name is “gene”, the password is
“pppWWW”, the assigned user role type is “role 1", and the group is “SD1”.
Note:
The following parameters are the user role types to be assigned:
role 1: super administrator
role 2: administrator
role 3: user
