Chapter 3. Operation
19
Before using the remote control, a user must first plug the IR receiver into the
rear panel of the VM0202H / VM0202HB and place the receiver where the IR
signal can be reached (see IR Remote Control, page 8).
Switching the Input
To change the input source of an output display using the remote control, do
the following:
1. Press the output port button (1-2) that you want to change.
2. Within 2 seconds press the input port button (1-2) you want the output
port to display.
Note: For the change to occur the input number must be pressed within 2
seconds of pressing the output number.
3. Repeat steps 1-2 to change additional ports.
Turning the Outputs on / off
To turn an output on / off using the remote control, do the following:
1. Press the output port button (1-2) that you want to turn off.
2. Within 2 seconds press the ON or OFF button on the remote control.
Note: If the ON or OFF button is pressed after 2 seconds of pressing the
output port number, all the displays are powered on or off instead of
just the intended output port.
3. Repeat steps 1-2 to turn the output back on / off.
Turning All Outputs on/off
To have all output displays turned on or off, regardless of the current power
statuses, press the ON or OFF button on the remote control.
