![Aten VM0202HB [53/55] Specifications](/views2/1977690/page53/bg35.png)
Appendix
43
Specifications
Function VM0202H VM0202HB
Video Input
Interface 2 x HDMI Type A Female (Black)
Impedance 100 Ώ
Max Distance 5 m
Video Output
Interface 2 x HDMI Type A Female (Black)
Impedance 100 Ώ
Max Distance 15 m 5 m
Video
Max Data Rate 10.2 Gbps (3.4 Gbps Per Lane) 18.0 Gbps (6.0 Gbps Per Lane)
Max Pixel
Clock
340 MHz 600 MHz
Compliance HDMI (3D, 4K, Deep Color)
HDCP 1.4 Compatible
Consumer Electronics Control
(CEC)
HDMI (3D, 4K, Deep Color)
HDCP 2.2 Compatible
Consumer Electronics Control
(CEC)
Max Resolution Up to 4096 x 2160 / 3840 x 2160
@ 60 Hz (4:2:0);
4096 x 2160 / 3840 x 2160 @ 30
Hz (4:4:4)
4096 x 2160 / 3840 x 2160 @ 60
Hz (4:4:4)
Max Distance Up to 15 m Up to 5 M
Control
RS-232 Connector: 1 x DB-9 Female (Black)
Baud Rate and Protocol:
Baud Rate: 19200
Data Bits: 8
Stop Bits:1
Parity: No
Flow Control: No
USB 1 x Micro USB; F/W Upgrade
IR 1 x Mini Stereo Jack Female (Black)
EDID Settings EDID Modes: Default / Port1 / Remix
Power
Connectors 1 x DC Jack (Black)
