Chapter 4. RS-232 Operation
31
CEC Command
Consumer Electronics Control (CEC) allows interconnected HDMI devices to
communicate with and respond to the same remote control.
The formula for the CEC command is as follows:
Command + Output + Number + Control + [Enter]
For example, to enable the CEC function on output port 1, type:
cec o01 on [enter]
The following tables show the possible values for the CEC command:
Note: Each command string can be separated with a space.
The following tables lists the available CEC commands:
Command Description
cec CEC command
Output Command Description
o Output command
Port number Description
yy 01~02 (default is 01)
* All output ports
Control Description
off Disable CEC (default)
on Enable CEC
Command
Output
Command
Output
Port
Control Enter Description
cec
o yy
*
off [Enter] CEC off for output port yy
(default)
(yy:01~02, *)
cec
o yy
*
on [Enter] CEC on for output port yy
(yy:01~02, *)
