VM0202H / VM0202HB User Manual
28
Note: 1. Each command string can be separated with a space.
2. Skip the output port command to automatically switch the audio
of all output ports.
The following tables lists the available Audio Switch commands:
Mode Description
Plugin When the HDMI input(s) is/or are
plugged in
Plugout When the HDMI input(s) is/or are
unplugged
Control Description
auto Auto switch to the latest detected input
source
next Auto switch to the next available input
source
prev Auto switch to the previous available
input source
off Disable auto switch mode
Command
Output
Command
Output
Port
Mode Control Enter Description
swmode
o yy
*
plugin auto [Enter] Switch output port xx to
automatically switch to the latest
detected input source when the
HDMI input(s) is/or are plugged in
(yy:01~02, *).
swmode
o yy
*
plugin off [Enter] Disable auto switch when the
HDMI input(s) is/or are plugged
in.
swmode
o yy
*
plugout next [Enter] Switch output port xx to
automatically switch to the next
available input source when the
HDMI input(s) is/or are unplugged
(yy:01~02, *).
swmode
o yy
*
plugout prev [Enter] Switch output port xx to
automatically switch to the
previous available input source
when the HDMI input(s) is/or are
unplugged (yy:01~02, *).
swmode
o yy
*
plugout off [Enter] Disable auto switch when the
HDMI input(s) is/or are
unplugged.
