Chapter 4. RS-232 Operation
33
EDID Mode Command
Extended Display Identification Data (EDID) is a data that contains a display's
basic information and is used to communicate with the video source.
The formula for the EDID command is as follows:
Command + Control + [Enter]
For example, to use the Port1 EDID mode, type:
edid port1 [enter]
The following tables show the possible values for the EDID command:
Note: Each command string can be separated with a space.
The following tables lists the available EDID commands:
Command Description
edid EDID Mode command
Control Description
port1 Implement the EDID of the connected display
to Output 1, and pass it to the video source.
remix Implement the EDID of each connected
display according to its connection when the
VM0202H / VM0202HB is first powered on, or
immediately after selecting the Remix option.
default Implements ATEN’s default EDID. (default)
Command Control Enter Description
edid port1 [Enter] The EDID from Output 1 is passed to the video
source.
edid remix [Enter] The VM0202H / VM0202HB implements the
EDID of each connected display according to
its connection when the VM0202H /
VM0202HB is first powered on, or immediately
after selecting the Remix option.
edid default [Enter] ATEN’s default EDID is passed to the video
source.
