Aten VM0202HB [37/55] To set the switch mode to auto switch mode type
![Aten VM0202HB [37/55] To set the switch mode to auto switch mode type](/views2/1977690/page37/bg25.png)
Chapter 4. RS-232 Operation
27
2. Skip the output port command to mute or enable the audio of all
output ports.
The following tables lists the available Audio Switch commands:
Auto Switch Command
The Auto Switch command allows you to set different auto switch mode for the
connected HDMI outputs.
The formula for the Auto Switch command is as follows:
Command + Output + Number + Mode + Control + [Enter]
1. To set the switch mode to auto switch mode, type:
swmode plugin auto [Enter]
2. To set HDMI output port 2 to the previous available port when the current
port is unplugged, type:
swmode o02 plugout prev [Enter]
The following tables show the possible values for the Auto Switch
command:
Command
Output
Command
Output
Port
Control Enter Description
mute
o yy
*
on [Enter] Audio off for output port yy
(yy:01~02, *)
mute on [Enter] Audio off for all output ports
mute
o yy
*
off [Enter] Audio on for output port yy
(default)
(yy:01~02, *)
mute off [Enter] Audio on for all output ports
Command Description
swmode Auto switch command
Output Command Description
o Output command
Port number Description
yy 01-02 port (default is 01)
* All output ports
