Aten VM0202HB [32/55] The controller s serial port should be configured as follows

VM0202H / VM0202HB User Manual

2. The controller’s serial port should be configured as follows:

3. When a session is established with the VM0202H / VM0202HB, you can

control and configure the VM0202H / VM0202HB via RS-232

commands. For more information on commands, see Commands, page 23.

RS-232 Protocol

Baud Rate 19200

Data Bits 8

Parity None

Stop Bits 1

Flow Control None
