VM0202H / VM0202HB User Manual
26
The following tables lists the available Audio Switch commands:
Audio Mute Command
The Audio Mute command allows you to mute or unmute the connected HDMI
output ports. The default setting is off.
The formula for the Read command is as follows:
Command + Output + Number + Control + [Enter]
1. To mute the HDMI output port 1, type:
mute o01 on [Enter]
2. To unmute all the HDMI output ports, type:
mute o* off [Enter] or mute off [Enter]
The following tables show the possible values for the Audio Mute
command:
Note: 1. Each command string can be separated with a space.
Command
Input
Command
Input
Port
Output
Command
Output
Port
Control Enter Description
sw i xx o yy diso [Enter] Extract and output the
audio signal from the
Input Port xx to the
connected speakers.
(xx:01~02; yy:01)
sw N/A N/A N/A N/A audio off [Enter] Disable audio extract.
Command Description
mute Mute command
Output Command Description
o Output command
Port number Description
yy 01-02 port (default is 01)
* All output ports
Control Description
on Mute on; audio output is disabled
off Mute off; audio output is enabled
(default)
