Yamaha DRAG STAR XVS1100 (1999) [20/355] General specifications
![Yamaha DRAG STAR XVS1100 (1999) [20/355] General specifications](/views2/1121370/page20/bg14.png)
2-2
GENERAL SPECIFICATIONS
SPEC
Item Standard
Carburetor:
Type/quantity
Manufacturer
BSR37/2
MIKUNI
Spark plug:
Type
Manufacturer
Spark plug gap
BPR7ES/W22EPR–U
NGK/DENSO
0.7 X 0.8 mm
Clutch type: Wet, multiple-disc
Transmission:
Primary reduction system
Primary reduction ratio
Secondary reduction system
Secondary reduction ratio
Transmission type
Operation
Gear ratio 1st
2nd
3rd
4th
5th
Spur gear
78/47 (1.660)
Shaft drive
44/47 19/18 32/11 (2.875)
Constant mesh 5-speed
Left foot operation
40/17 (2.353)
40/24 (1.667)
36/28 (1.286)
32/31 (1.032)
29/34 (0.853)
Chassis:
Frame type
Caster angle
Trail
Double cradle
33
136 mm
Tire:
Type
Size front
rear
Manufacturer front
rear
Type front
rear
With tube
110/90-18 61S
170/80-15M/C 77S
BRIDGESTONE/DUNLOP
BRIDGESTONE/DUNLOP
EXEDRA L309/K555F
EXEDRA G546/K555
Maximum load-except motorcycle: 201 kg (5EL2 : 200kg)
Tire pressure (cold tire):
0 X 90 kg (0 X 198 lb) load *
front
rear
90 kg (198 lb) X Maximum load *
front
rear
200 kPa (2.00 kg/cm
2
)
225 kPa (2.25 kg/cm
2
)
225 kPa (2.25 kg/cm
2
)
250 kPa (2.50 kg/cm
2
)
* Load is the total weight of the cargo, rider,
passenger and accessories.
Brake:
Front brake type
operation
Rear brake type
operation
Dual disc brake
Right hand operation
Single disc brake
Right foot operation
