Yamaha DRAG STAR XVS1100 (1999) [23/355] Maintenance specifications
![Yamaha DRAG STAR XVS1100 (1999) [23/355] Maintenance specifications](/views2/1121370/page23/bg17.png)
2-5
Margin Thickness
Head Dia Face width Seat Width
MAINTENANCE SPECIFICATIONS
SPEC
Item Standard Limit
Timing chain:
Timing chain type/No. of links
Timing chain adjustment method
SILENT CHAIN/98L
Automatic
SSS
SSS
Rocker arm/rocker arm shaft:
Bearing inside diameter
Shaft outside diameter
Arm-to-shaft clearance
14.000 mm X 14.018 mm
13.985 mm X 13.991 mm
0.009 mm X 0.033 mm
14.036 mm
13.95 mm
0.086 mm
Valve, valve seat, valve guide:
Valve clearance (cold) IN
EX
0.07 X 0.12 mm
0.12 X 0.17 mm
SSS
SSS
Valve dimensions:
“A” head diameter IN
EX
“B” face width IN
EX
“C” seat width IN
EX
“D” margin thickness IN
EX
Stem outside diameter IN
EX
Guide inside diameter IN
EX
Stem-to-guide clearance IN
EX
47.0 X 47.2 mm
39.0 X 39.2 mm
2.1 mm
2.1 mm
1.2 X 1.4 mm
1.2 X 1.4 mm
1.1 X 1.5 mm
1.1 X 1.5 mm
7.975 X 7.990 mm
7.960 X 7.975 mm
8.000 X 8.012 mm
8.000 X 8.012 mm
0.010 X 0.037 mm
0.025 X 0.052 mm
SSS
SSS
SSS
SSS
1.8 mm
1.8 mm
0.8 mm
0.8 mm
SSS
SSS
SSS
SSS
0.08 mm
0.10 mm
