Konica Minolta CF2002P [110/162] When the message punch dust full please change appears

5.5 When the Message “Punch dust full Please change” Appears

5-42 CF2002/CF3102

Printer Panel Messages Chapter 5

5.5 When the Message “Punch dust full Please

change” Appears

If the punch kit PK-4 is installed in the finisher FN-8, the above message will appear

when the hole-punch waste container is full with punch scraps.

To empty the hole-punch waste container

Empty the hole-punch waste container, and then re-install it according to the

following procedure.

1 Slide the finisher away from the

printer.

2 Pull out the hole-punch waste

container.
