Konica Minolta CF2002P [87/162] To clear a paper misfeed in the duplex unit

5.4 When the Message “Paper jam at Jx” Appears

CF2002/CF3102 5-19

Printer Panel Messages Chapter 5

To clear a paper misfeed in the duplex unit

1 Open the duplex unit door.

2 Carefully pull out the paper.

3 Close the duplex unit door.
