Konica Minolta CF2002P [56/162] Loading paper chapter 4

4.5 Loading Paper

4-10 CF2002/CF3102

Loading Paper Chapter 4



Note

Do not load envelopes cross-

wise, as shown.



Tip

When loading overhead pro-

jector transparencies, load

them with the longer side as

the leading edge, as shown.



Note

Do not load overhead projector

transparencies lengthwise.
