Konica Minolta CF2002P [66/162] Loading paper chapter 4

4.5 Loading Paper

4-20 CF2002/CF3102

Loading Paper Chapter 4



Note

Do not load envelopes cross-

wise, as shown.



Tip

When loading Overhead Pro-

jector transparencies, load

them with the longer side as

the leading edge, as shown.



Note

Do not load Overhead Projec-

tor transparencies lengthwise,

as shown.
