Konica Minolta CF2002P [114/162] When the message near trouble appears

5.8 When the Message “Near trouble ## / ##” Appears

5-46 CF2002/CF3102

Printer Panel Messages Chapter 5

5.8 When the Message “Near trouble ## / ##” Appears

When the message shown below appears in the printer panel display, image

stabilization and printing functions for the printer have become unstable.

Press

once and check which error code is displayed.

If this message appears, contact your technical representative and inform them of

the error coad that is indicated.
