Konica Minolta CF2002P [80/162] Printer panel messages chapter 5

5.3 When the Message “No Staples” Appears

5-12 CF2002/CF3102

Printer Panel Messages Chapter 5

3 Slowly pull out the stapler unit as

far as possible.

4 Turn dial clockwise until the

staple cartridge moves to a

position from where it can be

removed.

 If the dial is turned too far, turn

it counterclockwise to adjust it.

5 Grasp both sides of the staple

cartridge, lift up the staple

cartridge, and then pull it out.
