SPECIFICATIONS
SPECIFICATIONS
MODEL SPYDER RT
ENGINE
ROTAX 991 60° V-Twin
Engine type
4-stroke, Dual Ov er Head Camshaft (DOHC), liquid cooled
Number o f cylinders
2
Number of valves 8valves
Bore
97 mm (3.82 in)
Stroke
68 mm (2.68 in)
Displacement
998 cm³ (60.9 in³)
Compression ratio
12.2:1
Type Dry sump with separate o il tank and oil cooler
Engine BRP Rotax paper type, replaceable
Oil filter
Transmission (SE5) BRP Rotax paper type, replaceable
Oil change with new
engine filter
SM5
3.9 L (4.1 qt (U.S. liq.))
Oil change with new
engine filter
4.2 L (4.4 qt (U.S. liq.))
Engine oil
Capacity
Oil change with new
engine and
HCM filters
SE5
4.3 L (4.5 qt (U.S. liq.))
Lubrication
Recommended Engine Oil
XPS SYNTH
ETIC BLEND OIL (SUMMER GRADE) (P/N 293
600 121)
or a 5W 40 semi-synthetic (minimum) or synthetic
motorcycle oil meeting the requirements for API service
SL, SJ, SH
or SG classification.
Type
Wet, multi-plate, manual operation through a hydraulic
piston, vacuum assist
SM5 model
Fluid DOT 4
Type
Centrif
ugal clutch + wet multi-plate clutch automatically
controlled by TCM
Engage-
ment
2000 +/- 20 0 RPM (centrifugal)
Clutch
SE5 model
Stall 3200 +/- 200 RPM (centrifugal)
Exhaust system 2 into 1 with catalytic converter
Air filter Paper element
GEARBOX
SM5 Sequential Manual 5-speed (SM5) with reverse
Type
SE5 Sequential Electronic 5-speed (SE5) with reverse
COOLING SYSTEM
Type Liquid cooled, single radiator with cooling fan
Type
Ethyl glycol/water mix (50% coolant, 50% water). Use
BRP
PREMIXED COOLANT (P/N 219 700 362)
or coolant
specifically designed for aluminum engines
Coolant
Capacity
3.2 L (.85 U.S. gal.)
PREDELIVERY 2010-1 35 / 39
