SPECIFICATIONS
MODEL SPYDER RT
WEIGHT AND LOADING CAPACITY
Dry weight (Spyder RT)
400 kg (882 lb)
Dry weight (Spyder RT Audio &
Convenience Package)
413 kg (911 lb)
Dry weight (Spyder RT-S)
422 kg (930 lb)
Capacity
55 L (14.5 U.S. gal.)
Front storage compartment
Maximum load
16 kg (35 lb)
Capacity
1.8 L (.5 U.S. gal.)
Glove box
Maximum load
2kg (4lb)
Capacity
23.5 L (6.2 U.S. gal.)
Side storage compartment
Maximum load
7kg (15lb)
Capacity
40.5 L (10.7 U.S. gal.)
Rear storage compartment
Maximum load
9kg (20lb)
Total vehicle load allowed (including operator, passenger, cargo and added
accessories)
240 kg (525 lb)
Gross vehicle weight rating (GVWR)
663 kg (1,462 lb)
Maximum weight on trailer tongue
18 kg (40 lb)
Maximum towed weight (trailer and cargo)
180 kg (400 lb)
Because of our ongoing commitment to product quality and innovation, BRP reserves the right, at any time, to
make changes in design and specifications and/or to make additions to, or improvements in its products without
imposing any obligation upon itself to install them on its previously manufactured products.
PREDELIVERY 2010-1 39 / 39
