SPECIFICATIONS
MODEL SPYDER RT
BRAKES
Type
Foot-actuated, fully integrated hydraulic 3-wheel braking
system with ABS and EBD
Front brake Dual discs (250 mm (9.8 in) x 6 mm (.24 in)) with 4 piston calipers
Rear brake Single disc (250 mm (9.8 in) x 6 mm (.24 in)) with 1 piston caliper
Capacity
530 ml (17.9 U.S. oz)
Brake fluid
Type DOT 4
Parking brake Mechanical, electrically actuated to the rear caliper
Minimum brake pad thickness
1mm (.04in)
Minimum brake disc thickness
5.33 mm (.21 in)
Maximum brake disc warpage
0.13 mm (.005 in)
TIRES
Front Kenda KR21 MC 165/65R14 47H (special motorcycle type)
Type (use only tires recommended by
BRP)
Rear Kenda KR21 MC 225/50R15 68H or 76H (special motorcycle type)
Front
Nominal.: 103 kPa (15 PSI)
Min.: 89 kPa (13 PSI)
Max.: 117 kPa (17 PSI)
Nominal.:
193 kPa (28 PSI)
Min.: 179 kPa (26 PSI)
Max.: 207 kPa (30 PSI)
Pressure
Rear
NOTE: The pressure difference between the left and right side
tire should not exceed 3.4 kPa (.5 PSI).
Front
2.5 mm (3/32 in)
Minimum tire tread depth
Rear
4 mm (5/32 in)
WHEELS
Front
355 mm (14 in) x 127 mm (5 in)
Size (diameter X width)
Rear
381 mm (15 in) x 178 mm (7 in)
Front wheel nuts torque
90 N•m to 120 N•m (66 lbf•ft to 89 lbf•ft)
Rear drive axle nut torque
123 N•m to 137 N•m (91 lbf•ft to 101 lbf•ft)
DIMENSIONS
Overall length
2 667 mm (105 in)
Overall width
1 572 mm (62 in)
Overall height
1 600 mm (63 in)
Seat (top) height
750 mm (29.5 in)
Wheelbase
1 708 mm (67 in)
Front wheel track
1 384 mm (54.5 in)
Ground clearance, front and under engine
115 mm (4.5 in)
38 / 39 2010-1 PREDELIVERY
