PARTS TO BE INSTALLED
ITEMS DESCRIPTION
5
Storage cover actuator connector
(option packag
e)
6
Storage cover switch connector
(option packag
e)
7
Storage cover cable
8 12 V power outlet
9
Storage compa
rtment light
(option package)
5. Install headlight harness clip (from PDI kit) on
vehicle frame as shown (on both side).
rbl2010-002-350_a
1. Headligh
t harness clip
6. Cut locking tie holding headlight harness.
rbl2010-002-351
7. Insert headlights harness into clips as shown.
rbl2010-002-352
LH SIDE
rbl2010-002-353
RH SIDE
8. Do not let auxiliary lights harness hang near
shock absorber. Properly insert it into clips (on
both sides).
rbl2010-002-354
CORRE
CT INSTALLATION
10 / 39 2010-1 PREDELIVERY
