SPECIFICATIONS
MODEL SPYDER RT
Accessories 40 A
TCM valves (SE5 model) 20 A
Rectifier 60 A
Main fuse 40 A
Dynamic Power Steering (DPS) motor 40 A
VSS pump 40 A
Headlights 30 A
Fuse
(Under seat)
VSS valves 25 A
FUEL SYSTEM
Fuel delivery Type
Multi-point Electronic Fuel Injection (EFI)
with ETC (Electronic Throttle Control)
Dual thrott
le body (51 mm) with an actuator
Fuel pump Type Electrical module in fuel tank
Idle speed 1400 ± 100 RPM (electronically controlled, not adjustable)
Type Regular unleaded gasoline
Inside North America
Recommended for optimum performance: 91 (R+M)/2
Minimum: 87 (R+M)/2
Fuel
Octane rating
Outside North America
Recommended for optimum performance: 95 RON
Minimum: 92 RON
Fuel tank capacity
25 L (6.6 U.S. gal.)
DRIVE SYSTEM
Final drive type Carbon reinforced drive belt
Final drive ratio 28/79
STEERING
Type Dynamic Power Steering (DPS)
FRONT SUSPENSION
Suspension type Double A-arm with anti-roll bar
Suspension travel
151 mm (5.9 in)
Qty
2
Shock absorber
Type Oil damper
Spring preload adjustment 5 position cam adjustment
REAR SUSPENSION
Suspension type
Air Controlled Suspension (ACS)
Compressor-controlled (ACS with remote adjustment only)
Swing
arm with monoshock
Suspension travel
145 mm
(5.7 in)
Qty
1
Shock absorber
Type Oil damper
Preload adjustment (ACS with manual adjustment) Adjustable air pressure:135 kPa to 625 kPa (20 PSI to 90 PSI)
Prel
oad adjustment (ACS w ith remote adjustment)
5 pos
itions
PREDELIVERY 2010-1 37 / 39
