Can-Am Spyder RT SM5 2010 [5/39] Front wheels installation
![Can-Am Spyder RT SM5 2010 [5/39] Front wheels installation](/views2/1012801/page5/bg5.png)
UNCRATING
ITEM DESCRIPTION (L
OCATION)
QTY
10
Service cover plastic rivet (front cargo
module)
2
11
Battery post screw (battery) 2
12 M6 x 20 screw (front panels) 2
13 Plastic wash
er (front panels)
2
14
M14 nut (headlights) 2
15
Clip (hea dlig hts)
2
16 M8 x 20 screw (
front fenders)
8
17
Windshield trim 2
18 M6 x 20 screw (windshie ld)
4
19 M5 x 20 scre
w (windshie ld )
2
20 M5 retaining nut (w indshield) 2
21 Mudguard 2
22 M6 retain
ing nut (Mudguards)
4
23 M6 x 20 screw (Mudguards)
4
Option Package
ITEM DESCRIPTION QTY
24 Antenna
1
25 Antenna rubber cap
1
26 M6 stainless steel lock washer
1
Front Wheels Installation
WARNING
SE5 mo
dels are automatically set in neutral
posit
ion when engine is stopped. Always
secur
e the rear wheel of vehicle with proper
block
s to avoid moving.
WARNING
No one should be standing in front or at the
back of the vehicle while straps are being cut.
1. Remove strap retaining front of vehicle to crate
base.
rbl2010-002-010_a
1. Front strap
2. Remove strap retaining side of vehicle to crate
base.
rbl2010
-002-011_a
1. Side strap
3. Remove strap on the RH caliper.
rbl2010-002-012_a
1. Caliper strap
NOTE: The following steps will describe two
methods to install front wheels on vehicle. The
conventional one uses a hydraulic jack and the
alternate one uses a chain block. Use the proper
method according to your shop layout.
PREDELIVERY 2010-1 5 / 39
