Product Description and
Specifications
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Intended Use
The power tool is intended as a stationary machine for making
straight lengthways and crossways cuts in wood. In this, hori-
zontal mitre angles from –52° to +60° as well as vertical bev-
el angles from 47° (leftward) to 47° (rightward) are possible.
The capacity of the power tool is designed for sawing hard-
wood and softwood, as well as particle and fibre board.
When using appropriate saw blades, sawing aluminium pro-
files and plastic is also possible.
Product Features
The numbering of the components shown refers to the repre-
sentation of the power tool on the graphic pages.
1 Dust bag
2 Extraction adapter
3 Laser warning label
4 Handle
5 Locking lever
6 Blade guard
7 Transport handle
8 Retracting blade guard
9 Fence extension
10 Fence
11 Saw-Table extension
12 Mounting holes
13 Insert plate
14 Mitre detent override
15 Locking knob for various mitre angles
16 Mitre detent lever
17 Bevel lock lever
18 Detents for standard mitre angles
19 Recessed handles
20 Allen key (6 mm/4 mm)
21 Allen key (2 mm)
22 Material clamp
23 Roller
24 Right bevel angle indicator (0° to 47°)
25 Chip deflector
26 Glide mechanism lock lever
27 Laser protection cap
28 Glide arm
29 Adjusting screw of depth stop
30 Depth stop
31 Transport safety-lock
32 Scale for bevel angle
33 Left bevel angle indicator (47° to 0°)
34 Adjustment knob for 22,5° bevel angle
35 Lock screw of the material stop
36 Material stop
37 Scale for mitre angle (horizontal)
38 Saw table
39 Rotary knob for adjustment of the bevel angle range
40 Saw blade
41 Sawdust ejector
42 Locking screw of linkage 43
43 Linkage of the retracting blade guard
44 Front fastening screw
(cover plate/retracting blade guard)
45 Rear fastening screw
(cover plate/retracting blade guard)
46 Cover plate
47 Spindle lock
48 Allen screw (size 6 mm) for mounting of saw blade
49
Clamping flange
50 Interior clamping flange
51 Clamping lever of the saw-table extension
52 Clamping lever of the fence extension
53 Cover plate tab
54 Glide movement controller
55 Set screws for damping
56 Mounting holes for material clamp
57 Wing bolt
58 Threaded rod
59 Mitre angle indicator
60 On/Off switch
61 Laser on/off switch (for marking of cutting line)
62 Screws for insert plate
63 Clamping screw of the material stop
64 Adjustment screw for laser position (flush levelling)
65 Screws for laser protection cap
66 Fastening screw for laser mounting plate
67 Fastening screw for laser housing
6870
Set screws for 0° basic setting (bevel angle)
71 Set screw for 45° basic setting (leftward bevel angle)
72 Set screw for 45° basic setting (rightward bevel angle)
73 Set screws of scale 37 for mitre angles
74 Screw for mitre angle indicator
75 Set screw for clamping force of lock lever 17
76 Velcro strap
Accessories shown or described are not part of the standard deliv-
ery scope of the product. A complete overview of accessories can
be found in our accessories program.
