Bosch GCM 12 GDL [39/456] Adjusting bevel angles

English | 39

Bosch Power Tools 1 609 929 W31 | (22.3.11)

Adjusting the Glide Movement of the Glide Arm

(see figure F)

The glide mechanism of glide arm 28 is factory-preset, and

not set to glide movement upon delivery of the power tool.

The glide movement of the glide movement controller can be

individually adjusted on the controller 54:

Hard – for more controlled work motion;

Soft – for fast saw cuts.

–For softer damping, loosen both set screws 55 using the

Allen key (4 mm) 20

tighten both set screws 55 for harder damping.

Clamping the Workpiece (see figure G)

To ensure optimum working safety, the workpiece must al-

ways be firmly clamped.

Do not saw workpieces that are too small to clamp.

– Press the workpiece firmly against the fence 10.

– Insert the material clamp 22 provided into one of the holes

56 intended for it.

– Loosen the wing bolt 57 and adapt the material clamp to

the workpiece. Tighten the wing bolt again.

– Firmly clamp the workpiece by turning the threaded rod

58 in clockwise direction.

Adjusting Mitre Angles

To ensure precise cuts, the basic adjustment of the machine

must be checked and adjusted as necessary after intensive

use (see “Checking and Adjusting the Basic Adjustment”,

page 43).

f Always tighten the locking knob 15 firmly before saw-

ing. Otherwise the saw blade can become wedged in the

workpiece.

Adjusting Standard Mitre Angles (see figure H)

For quick and precise adjustment of commonly used mitre an-

gles, detents 18 have been provided for on the saw table:

– Loosen the locking knob 15 in case it is tightened.

– Pull lever 16 and rotate the saw table 38 left or right to the

requested detent.

– Release the lever again. The lever must be felt to engage in

the detent.

Adjusting Any Mitre Angle (see figure I)

The mitre angle can be set in the range from 52° (left side) to

60° (right side).

– Loosen the locking knob 15 in case it is tightened.

– Pull lever 16 and at the same time, push mitre detent over-

ride 14 down at the front.

This locks lever 16 and the saw table can move freely.

– Turn the saw table 38 left or right by the locking knob until

the angle indicator 59 indicates the requested mitre angle.

– Tighten the locking knob 15 again.

– To loosen the lever 16 again (for adjusting standard mitre

angles), pull the lever upward.

The mitre detent override 14 snaps back to its original po-

sition and lever 16 can re-engage into the detents 18.

Adjusting Bevel Angles

To ensure precise cuts, the basic adjustment of the machine

must be checked and adjusted as necessary after intensive

use (see “Checking and Adjusting the Basic Adjustment”,

page 43).

The vertical bevel angle can be adjusted in a range from 47°

(leftward) to 47° (rightward).

For quick and precise setting of frequently used bevel angles,

stops have been provided for the angles 0°, 22.5°, 45° and

47°.

Adjusting the Lefthand Bevel Angle

Range(45° to 0°)

– Pull the left fence extension 9 completely outward. (see

“Extending the Fence”, page 38)

– Loosen the lock lever 17.

– Tilt the glide arm via handle 4 leftward until the angle indi-

cator 33 indicates the desired bevel angle.

– Hold the glide arm in this position and tighten lock lever 17

again.

The clamping force of the lock lever must securely hold the

position of the glide arm at any bevel angle.

Adjusting the Righthand Bevel Angle

Range(0° to 45°) (see figure J)

– Pull the right fence extension 9 completely

outward. (see “Extending the Fence”,

page 38)

– Loosen the lock lever 17.

– Lightly tilt the glide arm leftward out of the 0°position via

handle 4 and turn rotary knob 39 until the desired bevel

angle range is indicated.

– Tilt the glide arm via handle 4 to the right until angle indica-

tor 24 indicates the desired bevel angle.

– Hold the glide arm in this position and tighten lock lever 17

again.

The clamping force of the lock lever must securely hold the

position of the glide arm at any bevel angle.

Standard 0° Bevel Angle

To enable simple and swift resetting of the standard 0° bevel

angle, rotary knob 39 will engage in the bevel angle range

– Tilt the glide arm from right to left over the 0° position.

Adjusting the Complete Bevel Angle

Range(–47° to +47°)

– Pull both fence extensions 9 completely out-

ward. (see “Extending the Fence”, page 38)

– Loosen the lock lever 17.

– Lightly tilt the glide arm leftward out of the

0°position via handle 4 and turn rotary knob 39 until the

desired bevel angle range is indicated.

– Tilt the glide arm via handle 4 to the left or right until angle

indicator 33 or 24 indicate the desired bevel angle.

Left Right

0°

15°; 22.5°;

31.6°; 45°

15°; 22.5°;

31.6°; 45°; 60°
