36 | English
1 609 929 W31 | (22.3.11) Bosch Power Tools
Technical Data
Noise/Vibration Information
Measured sound values determined according to EN 61029.
Typically the A-weighted noise levels of the product are:
Sound pressure level 93 dB(A); Sound power level
106 dB(A). Uncertainty K =3 dB.
Wear hearing protection!
Vibration total values (triax vector sum) determined accord-
ing to EN 61029:
Vibration emission value a
h
<2.5m/s
2
, Uncertainty
K=1.5m/s
2
.
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 61029 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 61029,
EN 60825-1 according to the provisions of the directives
2004/108/EC, 2006/42/EC.
Technical file at:
Robert Bosch GmbH, Dept. PT/ESC,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 24.03.2011
Assembly
f Avoid unintentional starting of the machine. During as-
sembly and for all work on the machine, the power plug
must not be connected to the mains supply.
Delivery Scope
Carefully remove all parts included in the delivery from their
packaging.
Remove all packaging material from the machine and the ac-
cessories provided.
Before starting the operation of the machine for the first time,
check if all parts listed below have been supplied:
– Sliding mitre saw with premounted saw blade
– Locking knob 15
–Dust bag 1
– Allen key 20
– Allen key 21
(below laser protection cap 27)
– Material clamp 22
Note: Check the power tool for possible damage.
Before further use of the machine, check that all protective
Sliding Mitre Saw GCM 12 GDL Professional
Article number
3 601 M23 600
3 601 M23 630
3 601 M23 670
3 601 M23 660 3 601 M23 690
Rated power input
W 2000 1500 1800
No-load speed
min
-1
3800 3800 3800
Reduced starting current
z zz
Laser type
nm
mW
635
<1
635
<1
635
<1
Laser class
2 22
Weight according to EPTA-Procedure
01/2003
kg 32.1 32.1 32.1
Protection class
/II /II /II
Permissible workpiece dimensions (maximal/minimal) see page 40.
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
Dimension of suitable saw blades
Saw blade diameter
mm 305
Blade body thickness
mm 1.7–2.6
Mounting hole diameter
mm 30
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
OBJ_BUCH-1360-001.book Page 36 Tuesday, March 22, 2011 12:01 PM
