Configuring and Maintaining the FC-26

8 Configuring and Maintaining the FC-26

8.1 IR Learning

Note: While learning is in progress, the four IR Out LEDS light and the FC-26 is

not available for normal operation.

At the start and end of learning a message is sent to all attached clients.

To perform IR learning, the IR remote control must be approximately five to seven

centimeters (2” and 2.7”) from the FC-26 front panel.

To teach the FC-26 an IR command:

1. Put the FC-26 in IR Learning mode either by sending the P3000 command,

(see Section 11.2) or by using the Web pages, (see Section 7.6).

The four IR Out LEDs light, the device is no longer in normal operation, and

the FC-26 sends an IR Leaning start message to all connected clients.

2. Using the IR remote control, send the required command to the FC-26.

The FC-26 processes the IR signal and generates the pronto code. When

using the Web page for IR learning, the FC-26 also displays the learned

command code on screen. (This command can be copied/pasted to other

applications, for example, K-Touch when creating a driver.) The FC-26 then

sends the IR Leaning stop message to all connected clients to indicate

return to normal operation.

3. Optional—Test the command if using the IR Learning Web page.

Test results are displayed on screen.

4. Save the learned command.
