Kramer FC-26 [40/68] Default logon authentication

Default Communication Parameters

10 Default Communication Parameters

RS-232

Protocol 3000

Baud Rate:

115200

Data Bits:

Stop Bits:

Parity:

None

Note: The FC-26 is dispatched from the factory with DHCP enabled and a random

IP address. After performing a factory reset, the DHCP and the IP address are set

to the values shown below.

Ethernet

DHCP:

Off

IP Address:

192.168.1.39

Host Name:

FC-26-xxxx

where xxxx are the last four digits of the serial

number of the device

Subnet Mask:

255.255.0.0

Gateway:

192.168.0.1

Maximum Simultaneous

Connections:

TCP Port 1:

5001

TCP Port 2:

5002

UDP Port:

50000

Default Logon Authentication

Web Page Access

User name:

Admin

Password:

Admin
